General
Power supply : DC 6.3 V (Using the AC Power Adapter/Charger)
DC 7.2 V (Using battery pack)
Power consumption
LCD monitor off, viewfinder on : Approx. 5.3 W
LCD monitor on, viewfinder off : Approx. 6.5 W
LCD monitor on, viewfinder on : Approx. 7.1 W
Format : DV Format (SD mode)
Signal format : PAL Standard
Video signal recording format : Digital Component Recording
Cassette : Mini DV Cassette
Tape Speed : SP: 18.8 mm/s
LP: 12.5 mm/s
Maximum recording time : SP: 60 min.
LP: 90 min. (using M-DV60ME cassette)
Pickup : 1/3" CCD
Lens : F1.8, f = 5 to 50 mm, 10:1 Power Zoom Lens
Filter diameter : ø37 mm
LCD monitor : 3.8" diagonally measured, LCD panel/TFT active matrix system
Viewfinder : Electronic viewfinder with 0.55" colour LCD
Speaker : Monaural
Operating temperature : 0°C to 40°C
Operating humidity : 35% to 80%
Storage temperature : –20°C to 50°C
Dimensions : 72 (W) x 94 (H) x 128 (D) mm
(with the LCD monitor closed, and with the viewfinder fully tilted
downward and pushed back in)
Weight : Approx. 670 g
Connectors
S-Video output : Y: 1Vp-p, 75 W, analogue output
C: 0.29 Vp-p, 75 W, analogue output
Video output : 1 Vp-p, 75 W unbalanced, analogue output (via AV OUT connector)
JLIP/Digital still output : ø3.5 mm, 4-pole, mini-head jack (compatible with RC-5325 plug)
Audio output : –8 dBs, 1 kW analogue output (via AV OUT connector)
Headphone output : ø3.5 mm, stereo (via AV OUT connector)
External microphone input : –68 dBs, high impedance unbalanced with ø3.5 mm (stereo)
DV connector : 4-pin, IEEE1394 confirmity
(GR-DVL9600: input/output, GR-DVL9500: output only)
AC Power Adapter/Charger AA-V68EK
Power requirement : AC 110 V to 240 V`, 50/60 Hz
Power consumption : 20 W
Output
Charge : DC 7.2 V , 0.77 A
VTR : DC 6.3 V , 1.8 A
Dimensions : 94 (W) x 35 (H) x 122 (D) mm
Weight : Approx. 360 g
