HDSLR System » Microphone » UHF PLL 32 Channels Lavalier Microphone Wireless System
UHF PLL 32 Channels Lavalier Microphone Wireless System
UHF PLL 32 Channels Lavalier Microphone Wireless System
[Other]
Out of stock
Wireless Tour Guide System 32 Preset Channels adjust UHF 798-830MHz One Transmitter and one Receiver
Description

Dimensions EIA Standard 1-Rack Unit
Oscillation Mode PLL Synthesized
RF Stability ±0.005%
Carrier Frequency Range UHF 798-830MHz
Bandwidth 32MHz
Channels 40 Preset Channels
Maximum Deviation ±48KHz
Frequency Response 50Hz-15KHz ± 3dB
Carrier Frequency Power 100mW (50Ω)
AF Inputs Balanced XLR & 6.35mmφ combined Phone Jack
Headphone Outputs 6.35mmφ Stereo Phone Jack, w/ Volume Control
Headphone Impedance ≥16Ω
Power Supply DC12V/250mA


 Oscillation Mode PLL Synthesized
RF Stability ±0.005%
Frequency Range UHF 798-830MHz
Switching Bandwidth 32MHz
Channels 40 Preset Channels
Receiving Mode Single Tuning
Sensitivity 25KHz Deviation @ Inputs 7dBuV, S/N>78dB
Maximum Deviation ±48KHz
S/N >94d B (1KHz-A)
T.H.D. <3% 1KHz
Frequency Response 80Hz-15KHz ± 3dB
Power Output (32Ω) 2×35mW 1KHz
Headphone Impedance ≥16Ω
AF Outputs 3.5mmφ Stereo Phone Jack, w/ Volume Control
Power Supply 2 x AA Size Battery
Power Consumption Overall 3V/120mA
