DV format gives easy, single-VTR editing with superior digital picture quality of more than 500-line horizontal resolution and an S/N ratio of 50 dB
DVCPRO-based DV professional mechanism, which assures a quick response and outstanding reliability
PCM sound recording in 2 channels (48 kHz/16 bits) or 4 channels (32 kHz/12 bits)
High-density, high-quality DV recording is possible in both SP mode and the extended (1.5x recording time) LP mode. The LP mode allows recording of up to 3 hours.
DV/Mini-DV cassettes which can be played back in DVCPRO VTRs are used.
Handy wireless editing controller can be used for wired editing if desired.
Extensive editing functions are available such as Assemble/Insert with variable editing mode including Automatic Programmed Editing which allows to programme up to 40 sets of edit start and end points.
DV input/output terminal (i.LINK: IEEE1394)
5-pin editing terminal
8-mm control terminal
S-Video and AV line input/output terminals
Super linear slow playback provides smooth, natural slow playback.
General :
Power Source: AC 220 to 240 V ±10%, 50/60 Hz ± 10%
Power Consumption: 36 W (Power Off: Approx. 10 W)
Operating Temperature: 5 °C to 40 °C
Operating Humidity: 35% to 80%
Weight: 7.0 kg
Dimensions (W x H x D): 445 x 123 x 373.5 mm
System :
Recording Format: Digital video SD format
Video Recording Format: Digital component
Audio Recording Format: Digital PCM stereo 16-bit (48 kHz/2 ch), 12-bit (32 kHz/4 ch)
Digital Still Picture: Digital still picture output, Control signal input/output (Transfer rate: 115 kbps max.)
Tape Transport :
Tape Format: DV, Mini-DV
Tape Speed: [SP] 18.831 mm/s, [LP] 12.568 mm/s
Recording Time: 120 min. with AY-DV120EC (3 hours with AY-DV120EC in LP mode)
FF/REW Time: Approx. 70 sec. with AY-DV120EC, Approx. 50 sec. with AY-DVM60EC
Video :
Line In (RCA x 2)*: 1.0 Vp-p, 75 unbalanced
Line Out (RCA x 1): 1.0 Vp-p, 75 unbalanced
EURO-AV (21-pin x 2): 1.0 Vp-p, 75 unbalanced
S-Video In (4-pin x 2): [Y] 1.0 Vp-p, 75 , [C] 0.286 Vp-p, 75
S-Video Out (4-pin x 1): [Y] 1.0 Vp-p, 75 , [C] 0.286 Vp-p, 75
Audio :
Line In (RCA x 2)*: -60 dBV, In/Out impedance less than 1 k
EURO-AV (21-pin x 2): -60 dBV, In/Out impedance less than 1 k
Mic In (M3): 0.33 mV, 600 unbalanced
Line Out (RCA x 1): 309 mV, 10k unbalanced
Headphone (M3): 1 to 30 mV, 8 unbalanced
Connectors :
Antenna Input: UHF/VHF 75 unified coaxial antenna terminal
RF Output: PAL DIN
DV Input/Output: i.LINK (IEEE 1394·1995)
System: 5-pin editing terminal
8mm Control: LANC compatible
