F&V Spectra HD 4 EVF Kit + Loupe unit
F&V Spectra HD 4 EVF Kit + Loupe unit
F&V
Out of stock
The F&V SpectraHD 4 is a compact 4.3" monitor with a stunning 1280 x 720px high-resolution display.
Description

Quick Overview

The F&V SpectraHD 4 is a compact 4.3" monitor with a stunning 1280 x 720px high-resolution display. The SpectraHD 4 has a 170-degree viewing angle, 8-bit color depth, and a 900:1 contrast ratio which makes it a strong, standalone monitor not only for reference but also for focus pulling. An optional flip-down loupe completes the system, transforming the monitor into an Electronic Viewfinder (EVF).

The F&V SpectraHD 4 is a compact 4.3"" monitor with a stunning 1280 x 720px high-resolution display. The SpectraHD 4 has a 170-degree viewing angle, 8-bit color depth, and a 900:1 contrast ratio which makes it a strong, standalone monitor not only for reference but also for focus pulling.


An optional, flip-down loupe completes the system, transforming the monitor into an Electronic Viewfinder (EVF). The loupe is a practical solution for over the shoulder camera work or when shooting in bright environments. The loupe has a slight magnification, yet it retains full-screen viewing which makes framing your shot easy. The loupe is sold separately or as part of a kit.


Advanced software features make the SpectraHD 4 a perfect solution for professionals. The SpectraHD 4 is packed with key features such as: vectorscope, histogram, focus peaking, false color, and adjustable frame guides. The SpectraHD 4 gives you tools to understand your image signal, ensuring its overall integrity. The SpectraHD 4 will be capable of future firmware upgrades via its integrated mini-USB input.


The SpectraHD 4 has a lightweight and strong aluminum body with two mounting options: one 1/4""-20 and one Arri Rosette. It has an HDMI IN and OUT with loop-through as well as an SDI IN and OUT with loop-through. The SDI input supports 3G/HD/SD. Another powerful feature of the SpectraHD4 is its ability to convert from HDMI IN to SDI OUT.


The SpectraHD 4 has several available power options: a Sony NP-F battery plate, a DC2.5mm jack, and mini-XLR. The mini-XLR can also be used for multi-camera shoots to receive a tally signal from the switch-board, illuminating the monitor's integrated Tally Light.


Whether on-location or in the studio, the SpectraHD 4 has all the physical and internal features to make it a versatile, reliable companion on-set.

SKU 108011080201
Highlights
  • 4.3" LCD Display with 1280x720px Resolution with 170-degree Viewing Angle
  • HDMI to SDI Conversion
  • Histogram, Vectorscope, False Color and Zebra Overlays
  • Focus Peaking, Frame Guides, Audio Columns, Timecode, and DSLR Scale
  • 1/4"-20 and Arri Rosette Mounting Options
  • Multiple Power Options: Sony NP-F, DC2.5mm, Mini-XLR
  • Ability to Upgrade via mini-USB
Specs
  • Screen Size ...................................................... 4.3" (diagonal)
  • Pixels ............................................. 1280(H) x 3(RGB) x 720(V)
  • Viewing Angle ............................................................... 170º
  • Display Area ....................................... 93.6mm(H) x 58.2mm(V)
  • Aspect Ratio ................................................16:9/4:3
  • Selectable Color Depth ....................................... 24-bit (16,777,216 colors)
  • Brightness ............................................................... 400 cd/m²
  • Contrast Ratio ............................................................... 800:1
  • Compatible Input Formats ....................................... NTSC/PAL
  • HDMI Input/Output ................................. HDMI (type A)
  • SDI Input/Output .......................................... BNC Female (8Ω)
  • Acceptable Signal Types
  •   ITU-R BT.656:576i(50)
  •   SMPTE-125M:480i(59.94)
  •   SMPTE-274M:1080i(60/59.94/50),1080p (30/29.97/25/24/24sF/23.98/23.98sF)
  •   SMPTE-296M:720p (60/59.94/50)
  •   SMPTE-425M A/B:1080i(60/59.94/50),1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
  • TALLY ..................... Mini XLR
  • Operating Voltage ................................................... 6 - 18V
  • DC Power .................................................................. Max 6.2W
  • Operating Temperature ..................... 0ºC to 40ºC (32ºF to 104ºF)
  • Storage Temperature ..................... -20ºC to 60ºC (-4ºF to 140ºF)
Package Contents
  • (1) x SpectraHD 4
  • (1) x Loupe for SpectraHD 4
  • (1) x Regular BNC to Right Angle BNC Cable
  • (1) x D-tap to Mini-XLR Cable
  • (1) x Regular HDMI Right Angle Mini-HDMI
  • (1) x USB to mini USB (Software Update Cable)
  • (1) x AC Power Adapter 12V/1A/DC2.5mm
  • (1) x Junior Joint
