Viltrox DC-70 EX is a portable HDMI monitor which can be used for mirror less cameras,DSLR and digital HD camcorders' with HDMI/AV ports. Viltrox DC-70 EX is advanced 7" HDMI monitor featuresgreat portability, flexibility and high definition picture quality. It is perfectly used for: Seminar / out door real time broadcasting / Recording of digital movie / on site production /editing / monitoring and recording in R&D

Product Function:

- Wide viewing angle LCD screen
- Useful functions such as peaking and pixel-by-pixel zoom
- Controls camera shutter release, ensures the long-distance monitor.
- Moveable shoe adapter enables easy removal when using a camera that has an auto lock accessory shoe.
- Works with rechargeable battery or power adapter.

• - Viltrox DC-70 Clip-on LCD Monitor adopts with 7-inch TFT high resolution LCD panel, is loaded with pro-style features to help photo enthusiasts and video-graphers shoot high-quality HD video footage with their Interchangeable Lens Digital camera.
• -There is also pixel magnification and peaking facility which will ensure accurate focus confirming, give an enlarged pixel-perfect view of a selected portion of the Full HD image.
• -Viltrox DC-70 Clip-on LCD Monitor has two angle adjustment shoe adaptors, which including standard and Sony shoe; they fulfill the different angles need in the real shooting process.
• -DC-70 has two HDMI jacks and one AV jack to get the video signal from the camera; the shutter release jack successes to control shooting when DC-70 EX epitaxial the camera LCD display.
• DC-70 is a portable LCD monitor for use with an Interchangeable Lens Digital Camera or an Interchangeable Lens Digital HD Video Camera Recorder with an HDMI terminal and live view mode. It can display HDMI video output from the camera. The following functions help you to see the image more clearly and take better pictures.

General

Dimensions (W×H×D): Approx. 191×128×36 mm
Weight: Approx. 480g (Excluding battery)
Color: Black
Operating temperature: +0 to +40°C (+32 to +104°F)
Storage temperature: -20 to +60°C (-4 to +140°F)
Power Supply: DC 8V~18V
Battery: FM500H / QM71D / QM91D

Panel

LCD panel size: Approx 7'' inch
Resolution: 1280×800 pixels
Speaker: Yes
Input jack: Input jack 1 HDMI ×1 / Input jack 2 AV ×1 Input jack 3 DC IN (power adapter plug) Input jack 4 USB upgrade jack
Output jack: Headphones output jackΦ3.5/ Output jack 1 HDMI ×1

Package Includes:

1 x 7'' LCD Monitor
1 x Sun shade hood
1 x Standard shoe
1 x Sony shoe
1 x HDMI Cable Type A-Type C
1 x User manual
1 x Original Packing
