DJI - Zenmuse H3-2D Gimbal for the GoPro HERO3
DJI - Zenmuse H3-2D Gimbal for the GoPro HERO3
dji
Out of stock
In order for the Zenmuse H3-2D to work with the Phantom Quadcopter, an upgrade kit is required. The kit itemcode number is DJUPGRADEKIT
Description

The DJI Zenmuse H3-2D Gimbal for the GoPro HERO3 is a 2-axis gimbal for the GoPro HERO3 action camera. It allows you to shoot ultra-smooth aerial footage with your GoPro HERO3. It features a lightweight aluminum alloy design and a built-in IMU module. The Zenmuse H3-2D inherited the core algorithm from the Zenmuse Z15 gimbal, and it's compatible with multiple DJI flight control systems. Its functionality can be updated through firmware upgrades as well.

2-Axis Gimbal
The Zenmuse H3-2D Gimbal is designed for the GoPro HERO3. It's widely used in film and television productions, advertising aerial photography, etc. Even if the aircraft is in high-speed flight, it can still stabilize and control the GoPro camera precisely with the highest stability. The precision of control angle is within the range of ±0.08°, so picture or video output can reach the best quality.
Customized for GoPro HERO3
The H3-2D gimbal supports remote start/stop shooting and video transmission (video downlink required) for the GoPro HERO3. More features will be supported by future firmware upgrades.
Compatible with DJI Flight Control Systems
The H3-2D gimbal is compatible with DJI flight control systems. It can adjust the roll and pitch angle according to the accurate control of the Gimbal feedback and communicate with the MC in real-time. It supports WooKong-M, NAZA-M V1, NAZA-M V2, and Phantom. It will also support Ace One, WooKong-H, and NAZA-H. It doesn't support NAZA-M LITE and in order to work with the Phantom, an upgraded kit is required. The kit itemcode number is DJUPGRADEKIT and it is available from B&H.
Core Technology Inherited from the Zenmuse
The H3-2D gimbal inherited the core algorithm from the Zenmuse Z15 gimbal and the unmanned aircraft flying attitude stability control algorithm. Combined with the high precision sensors and brushless motors, the DJI Zenmuse H3-2D gimbal provides pixel level stabilized footage.
Independent IMU Module
The independent high-precision IMU module provides precise attitude data and the closed-loop control gives improved control accuracy. Without the requirement of complex installation and connection of many wires, it is also easy to assemble and remains stable when in flight.
Lightweight Aluminum Design
The aluminum alloy material and innovative mechanical design makes the gimbal lightweight. It weighs only 8.1 oz with the GoPro HERO3 attached. The structural design of the aluminum frame guarantees the strength of the gimbal.
Works with Phantom & Flame Wheel
The mechanical design, weight, and power supply will match the Phantom and Flame Wheel perfectly. The Phantom transmitter can be easily upgraded to give the pitch (tilt) control function of the gimbal, with a customized slider. No additional receiver channels are needed; it just uses the additional MC channels.
Online Upgrade
The functionality can be easily updated by online firmware upgrades.

Supported Camera GoPro HERO3
Controlled Angle Accuracy ±0.08°
Maximum Controlled Rotation Speed Tilt Axis: ±130°/s
Roll Axis: ±30°/s
Controlled Rotation Range Tilt Axis Control: -130 to +50°
Roll Axis Control: ±39°
Working Current/Voltage Static Current: 400 mA at 12 V
Dynamic Current: 600 mA at 12 V
Input Power Gimbal: 3 S (12 V) - 6 S (26 V)
GCU: 3 S - 6 S (LiPo)
System Requirements Windows XP (SP3)
Windows 7
Windows 8
Operating Temperature 14 to 122°F (-10 to 50°C)
Regulations FCC (USA)
IC (Canada)
RoHS (EU)
Dimensions Gimbal: 3.9 x 3.4 x 3.7" (99.5 x 85.5 x 92.75 mm)
GCU: 1.7 x 1.3 x 0.4" (42 x 32 x 9.3 mm)
Weight

Gimbal: 8.1 oz (230 g)
GCU: 0.8 oz (22 g)

DJI Zenmuse H3-2D Gimbal for the GoPro HERO3

















  • Damping Unit
  •































  • Gimbal Controller Unit
  •































  • Gimbal Video Signal Cable
  •































  • CAN-Bus Cable
  •































  • 8-Pin Cable
  •































  • Screw Package
  •































  • Spare Screw Package
  •
